Unitree's Dex5-S Brings a 22-DoF Robotic Hand to Developers for $6,500
Unitree's new Dex5-S packs 22 backdrivable joints into a human-sized robotic hand starting at $6,500, targeting the dexterity bottleneck holding back humanoids.
- Unitree launched the Dex5-S dexterous hand with 22 DoF at a 1:1 human hand size.
- Starting price is $6.5K, excluding tax and shipping, undercutting most research-grade hands.
- All 22 joints are backdrivable and include limit impact torque protection.
- Upgrade from the Dex5-1, which had 20 DoF (16 active, 4 passive) and up to 94 tactile sensors.
- Positions Unitree alongside SharpaWave and Shadow Hand in the top tier of commercial dexterous hands.
- Targets the manipulation bottleneck holding back humanoid platforms like the G1, H1, and H2.
Unitree prices its 22-DoF Dex5-S robotic hand at $6,500
Hangzhou robotics company Unitree has announced the Dex5-S, a five-finger robotic hand with 22 degrees of freedom, human-scale dimensions, and a starting price of US$6,500 before tax and shipping. Unitree says every degree of freedom is driven and backdrivable, placing the hand among the most highly actuated models available to robotics developers.
A degree of freedom, or DoF, represents an axis of motion that the mechanism can control. Backdrivability allows an external force to move a powered joint, which supports compliant contact and direct force control. Unitree also advertises impact torque protection at every joint, a safeguard intended to limit drivetrain damage during collisions and failed grasps. The company has not published enough detail to assess the protection system’s limits or implementation.
Two more axes, fully driven
Unitree specified the previous Dex5-1 with 20 DoF, divided into 16 active and four passive axes. Its 12 composite-transmission joints supported backdriving and force control, while an optional tactile system provided as many as 94 sensing points per hand at a 1,000 Hz sampling rate. Unitree demonstrated that model turning pages and manipulating a Rubik’s Cube on its G1, H1, and H2 humanoids.
The Dex5-1 assigned four active DoF to the thumb and three active plus one passive DoF to each finger. Unitree also claimed fingertip repeatability of ±1 millimeter. The Dex5-S raises the total to 22 and describes every axis as fully driven and backdrivable. Detailed actuator mapping remains unavailable, so the degree of independent control and any mechanical coupling still require confirmation.
How the field compares
Raw DoF totals can conceal meaningful architectural differences. A passive axis follows contact without its own actuator, while an active axis receives power. Independently actuated axes can accept separate commands; coupled axes share an actuator or transmission. Hand size, torque, tactile coverage, control bandwidth, and durability also affect performance.
| System | Published motion | Architecture and sensing | Commercial position |
|---|---|---|---|
| Shadow Dexterous Hand | 24 total DoF, 20 actuated | Tendon-driven research platform with multiple sensing options | Quote-based, established in robotics research |
| SharpaWave | 22 independently actuated DoF | Direct-drive architecture | Pricing varies by configuration |
| Dexcel Apex | 21 total DoF, 16 independently actuated | Tactile sensing across fingertips, phalanges, and palm | Research-focused platform |
| Sanctuary AI hand | 21 DoF | Miniaturized hydraulic actuation; Sanctuary claims testing beyond two billion cycles | Designed for Sanctuary’s robotic systems |
| Unitree Dex5-S | 22 fully driven DoF, according to Unitree | Backdrivable joints with impact torque protection | Starts at US$6,500 before tax and shipping |
Vendor specifications use different definitions and test methods, so the figures above provide architectural context rather than a performance ranking.
A lower entry price for manipulation
Unitree has used aggressive base pricing to expand adoption of its humanoid hardware. The company moved its G1 humanoid into mass production in 2024 with a base configuration priced around US$16,000. A Dex5-S pair would start at US$13,000, excluding tactile sensors, controllers, mounting hardware, taxes, shipping, and integration work.
For humanoid developers, dexterous manipulation remains difficult because contact-rich tasks require precise motion, force control, sensing, and large training datasets. Low-DoF grippers restrict the grasps and demonstrations a learning system can represent. A backdrivable 22-DoF hand provides a broader action space and can yield under contact, which may make teleoperation, imitation learning, and reinforcement learning safer for the mechanism.
Where developers could use it
- Human-motion retargeting: Human-scale dimensions reduce geometric scaling when mapping glove or vision-based demonstrations onto the robot. Joint topology, range of motion, and calibration still determine mapping quality.
- Bimanual research: A US$13,000 starting price for two hands lowers the hardware cost of studying coordinated tool use, handoffs, assembly, and deformable-object manipulation.
- Contact-rich training: Backdrivability and torque protection may reduce damage during exploratory policies, failed grasps, and unexpected collisions. Safe operating limits remain unpublished.
- Humanoid integration: Earlier Dex5 hardware has appeared on Unitree’s G1, H1, and H2 platforms. Unitree has yet to publish Dex5-S mounting, electrical, software, or compatibility documentation.
The missing parts of the spec sheet
| Open question | Why developers need the answer |
|---|---|
| Tactile sensing | Unitree has not confirmed whether the Dex5-S supports the Dex5-1’s optional 94-point, 1,000 Hz tactile array or introduces a different sensor package. |
| Force and speed | Fingertip force, continuous and peak joint torque, motion speed, payload, thermal limits, and duty cycle determine which tasks the hand can perform reliably. |
| Control stack | Available control modes, update rate, latency, time synchronization, communications bus, SDK support, and ROS integration affect real-time control and data collection. |
| Mechanical integration | Mass, power draw, connectors, mounting geometry, cable routing, and left-hand or right-hand configurations shape the integration effort. |
| Protection and durability | Developers need trip thresholds, reset behavior, cycle testing, ingress protection, maintenance requirements, and warranty terms to estimate operating risk. |
| Availability | Regional shipping dates, lead times, distributor support, and the contents of the base configuration remain unclear. |
Until Unitree publishes those details and independent testers measure force control, repeatability, latency, tactile performance, and durability, the US$6,500 figure is best treated as an entry price rather than the full cost of a research-ready hand.
